Creality Ender 3 V3 Plus

The Ender 3 V3 Plus from Creality offers enough space for even the boldest ideas with its huge build volume of 300 x 300 x 330 mm. Driven by an innovative CoreXZ motion system, the print head dances across the build platform at breathtaking speeds of up to 600 mm/s - but never sacrifices its precision.

Features at a glance:

• Build volume of 300 x 300 x 330 mm,
• Stable construction with two additional support rods for more stability of the Z-axis,
• CoreXZ motion system with two powerful motors,
• Max. printing speed of 600 mm/s, max. acceleration of 20 000 mm/s²,
• Two powerful motors on the Y-axis with a peak torque of 1000 Nm (500 Nm each) for smooth axis movements,
• Optimised direct drive extruder,
• Powerful 60 watt heating element heats up to 300 °C in 75 seconds,
• Unicorn tri-metal nozzle with integrated titanium alloy heatbreak,
• Efficient double fan for rapid cooling of the freshly printed layers,
• Automatic calibration.

A + Build Volume

The Ender 3 V3 Plus has a build volume of 300 x 300 x 330 mm for printing larger objects or multiple parts at once. So you can now really turn all your ideas into reality!

Robust and stable construction

The gantry and the base of the printer are made of a single aluminium alloy die-cast part in the shape of a robust triangle. Two additional support rods increase the stability of the overall construction and reduce the wobble of the Z-axis. Few screws and rounded corners give the Ender 3 V3 Plus an elegant appearance.

CoreXZ motion system for higher speeds

The 3D printer's X and Z axes are connected in a stable CoreXZ motion system and are supported by two high-torque motors attached to the base for coordinated and smooth movement of the axes. This not only ensures greater accuracy of the Z axis, but also achieves a top speed of an astonishing 600 mm/s and a maximum acceleration of 20,000 mm/s² with ease. That means: 12 times faster printing!

Two powerful motors on the Y-axis achieve a peak torque of 1000 Nm to smoothly move the print bed and the prints on it at high speed along two robust linear guide rods.

Direct drive extruder and 60-watt heating element

For better filament grip, the optimised extruder of the Ender 3 V3 Plus is supported by a support spring and a ball roller, ensuring clogging-free extrusion.

A powerful 60-watt ceramic heating element only needs 75 seconds to reach a temperature of 300 °C. This melts the filaments without fatigue, even at high speed.

Integrated, quick-change Unicorn tri-metal nozzle

The Ender 3 V3 Plus is equipped with a tri-metal nozzle. The copper nozzle with steel tip forms a unit with a heat break made of titanium alloy. The durable nozzle blocks heat development and can be easily replaced.

Attention! Let the nozzle cool down before touching it with your hand.

Efficient fans for instant model cooling

There are fans at the front and back of the print head that harden freshly printed layers quickly and evenly for better printing results.

Additional features:

• The printer is delivered in pre-assembled modules, easy and quick to assemble,
• Silent mode with ≤ 55 dB.
• Automatic one-tap calibration, automatic levelling, auto Z offset, auto input shaping test,
• Fully automatic tensioning of the XZ belt,
• Print Farm opportunity,
• Open source Creality OS, Creality Print Slicer, Creality Cloud App.
